Chicago Museum’s Smart Home Gets Makeover

Exhibit at Chicago Museum of Science & Industry includes donated equipment and time from Lutron, Sonance, Trufig, Middle Atlantic, AMX, Planet Waves and ReQuest.


The Chicago Museum of Science & Industry’s Smart Home was a microcosm of cooperation by various members of the custom electronics industry that donated their time and equipment. (Photo Credit: J.B. Spector, Museum of Science and Industry, Chicago)
Jason Knott · May 16, 2011

Since first opening in 2008, the Smart Home exhibit in Chicago’s Museum of Science & Industry has hosted more than 250,000 guests. But it wasn’t’ all that foot traffic that precipitated a makeover, it was new technology.

The exhibit, dubbed “Chicago’s Greenest Home,” is now outfitted with even more green technologies. The tech portion of the project was an example of some of the best levels of industry cooperation ever witnessed. Here’s a quick list of the tech participants.

Doherty Design Group: Led by former CEDIA president Tom Doherty, the company provided oversight and brought together many of the home automation partners to “make the smart home even smarter,” says the museum. Doherty also installed the Lutron products in the exhibition.

Integrated Control Experts (ICX): Based in Westmont, Ill., ICX’s Eric Lee provided the system design and project management for the three-week job.

GSLogic: Donated GSL Home, a turnkey software solution for AMX residential dealers. Custom programming by Gary Spaniola allows Museum guides to control custom scripts from the keypads.

Module Depot donated software modules for additional green system support.

Best Buy/Geek Squad: The installation labor for the job was donated by Geek Squad. According to Lee, the two Geek Squad technicians had never built a rack before, “but because of that were excited to have the opportunity. They had great attitudes and aptitude. They worked late into the evening at my office wiring the racks. We [ICX] loaded the software,” says Lee. The duo retrofit wiring within the home, and built the equipment rack. “I also taught them how to use various software tools, like Netlinx Studio, terminal emulator, and how to solder DB9 connectors for RS232 terminations,” adds Lee.

Photos: Chicago Museum’s Smart Home Gets Makeover

Meanwhile, Best Buy donated an Insignia 55-inch LED TV for the lounge, a 46-inch LED TV for the master bedroom, a 19-inch touchpanel for the kitchen, Sony S580 Blu-ray player, Casio Green Slim XGA projector for the upstairs bedroom, and an Acer Aspire Revo computer.

Lutron Electronics donated Sivoia QED shade control for the window treatments, and HomeWorks lighting control for the entire smart home.

AMX donated its whole-house automation system and control modules for the project.

Sonance donated its Invisible Series speakers and amplifiers for the living room and lounge, and amplifiers for the whole house. Trufig provided the light switches and outlets in the kitchen.

Middle Atlantic donated the rack, power and accessories for the job.

Planet Waves donated all of the interconnects and HDMI cabling. The connectors are all re-usable, fitting with the green sustainability theme of the project.

ReQuest loaned an F2 v5 two-zone audio and video server.
